Nylon Wing Nuts
Description
Nylon wing nuts are designed for applications requiring quick assembly or disassembly without tools. They are suitable for hand tightening and releasing in all situations where easy access or frequent breakdown is needed. Manufactured from high-strength Nylon 66, these nuts provide durability, corrosion resistance, and insulation properties, making them ideal for use in electronics, cleanrooms, and light mechanical assemblies.
Features
- Material: Nylon 66
- Flame Rating: UL94-V2
- Temperature Range: -35°C to +85°C
- Excellent insulation and corrosion resistance
- Lightweight and easy to tighten or remove by hand
- Available in white or black as standard
- Sizes from M3 to M12 standard; other sizes on request
Dimensions (mm)
| Size | A | B | C | D | E |
|---|---|---|---|---|---|
| M3 | 0.29 | 16.5 | 8 | 7.5 | 1.8 |
| M4 | 3.9 | 18 | 8.5 | 7.8 | 1.7 |
| M5 | 5 | 21.7 | 10.7 | 9.6 | 2.2 |
| M6 | 5.8 | 26.3 | 12.5 | 11.6 | 2.7 |
| M8 | 7.7 | 34 | 16.3 | 13.8 | 2.9 |
| M10 | 9.7 | 41.9 | 20.3 | 17.3 | 3.3 |
| M12 | 11.7 | 50.5 | 24.5 | 20.6 | 3.7 |
Part Number Reference
| Part Number | Size | Colour |
|---|---|---|
| N1020300W | M3 | White |
| N1020400W | M4 | White |
| N1020500W | M5 | White |
| N1020600W | M6 | White |
| N1020800W | M8 | White |
| N1021000W | M10 | White |
| N1021200W | M12 | White |
| N1020300B | M3 | Black |
| N1020400B | M4 | Black |
| N1020500B | M5 | Black |
| N1020600B | M6 | Black |
| N1020800B | M8 | Black |
| N1021000B | M10 | Black |
| N1021200B | M12 | Black |
| Document No.: MSDS-N102 | Revision: 01 | Date of Issue: 2 November 2025 |
