Nylon Flange Nuts
Description
Nylon Flange Hex Nuts are precision-engineered for use with externally threaded components such as machine screws and threaded rods. Made from high-quality Nylon 66, these nuts provide a reliable and lightweight fastening solution for applications requiring electrical insulation, corrosion resistance, and non-metallic assembly. Designed for use with a spanner or socket drive, they deliver strong mechanical performance while protecting delicate surfaces from damage.
Features
- Material: Nylon 66
- Flame Rating: UL94-V2
- Temperature Range: -35°C to +85°C
- Lightweight and corrosion resistant
- Suitable for spanner or socket drive tightening
- Excellent insulation and non-conductive properties
- Available in white or black
- Standard sizes: M3 – M12 (custom sizes available up to M24)
Dimensions (mm)
| Size | A | B | C | D |
|---|---|---|---|---|
| M3 | 3.3 | 5.5 | 7.8 | M3 |
| M4 | 4.2 | 6.9 | 9.9 | M4 |
| M5 | 5.0 | 7.8 | 11.5 | M5 |
| M6 | 6.0 | 9.8 | 13.9 | M6 |
| M8 | 7.8 | 12.7 | 17.5 | M8 |
| M10 | 9.7 | 15.5 | 21.5 | M10 |
| M12 | 11.6 | 17.5 | 23.6 | M12 |
Part Number Reference
| Part Number | Size | Colour |
|---|---|---|
| N1030300W | M3 | White |
| N1030400W | M4 | White |
| N1030500W | M5 | White |
| N1030600W | M6 | White |
| N1030800W | M8 | White |
| N1031000W | M10 | White |
| N1031200W | M12 | White |
| N1030300B | M3 | Black |
| N1030400B | M4 | Black |
| N1030500B | M5 | Black |
| N1030600B | M6 | Black |
| N1030800B | M8 | Black |
| N1031000B | M10 | Black |
| N1031200B | M12 | Black |
| Document No.: MSDS-N103 | Revision: 01 | Date of Issue: 2 November 2025 |
