Datasheet – Nylon Heatsink Push-in Rivet
TDS Banner

Nylon Heatsink Push-in Rivet

Nylon Heatsink Push-in Rivet

Description

Our Nylon Heatsink Push-in Rivets are designed to fasten a heatsink to a processor chip on a PCB quickly and securely. The integrated metal spring applies continuous pressure to the heatsink until thermal adhesive cures, ensuring consistent thermal contact and stability. Made from high-quality Nylon, they offer strength, insulation, and easy installation for electronic assembly applications.

Features

  • Quick push-in installation – no tools required
  • Metal spring maintains constant pressure during adhesive curing
  • Ideal for securing heatsinks on processors or ICs
  • Available in black or white nylon
  • UL94-V2 flame rating
  • Operating temperature: -30°C to +85°C
  • RoHS compliant

Technical Details

Material Nylon 6
Colour Black or White
Temperature Range -30°C to +85°C
Flammability Rating UL94-V2
Compliance RoHS

Part Number Details

White (W) Black (B)
SU-HSR-2.6WSU-HSR-2.6B
SU-HSR-3.1WSU-HSR-3.1B
SU-HSR-3.6WSU-HSR-3.6B
SU-HSR-5.8WSU-HSR-5.8B
SU-HSR-6.6WSU-HSR-6.6B
SU-HSR-8.7WSU-HSR-8.7B
SU-HSR-13WSU-HSR-13B
SU-HSR-13.6WSU-HSR-13.6B
SU-HSR-15.6WSU-HSR-15.6B
SU-HSR-17.8WSU-HSR-17.8B
SU-HSR-24WSU-HSR-24B
SU-DG-21WSU-DG-21B
IMPORTANT: This data sheet and its contents (the “Information”) are owned by Sucatec or are licensed to it. The Information is provided solely for informational purposes related to the products described. No license is granted for any other use, and no intellectual property rights are transferred. The Information is subject to change without notice and supersedes all previous data sheets. While believed to be accurate, Sucatec assumes no responsibility for the accuracy or completeness of the Information, any errors or omissions, or any reliance on it. Users should verify the Information and the suitability of the products for their purposes independently. Liability for any loss or damage resulting from reliance on the Information or its use (including liability due to negligence or if Sucatec was aware of potential loss or damage) is excluded. © 2025 Sucatec
Document No.: DS-HSR Revision: 01 Date of Issue: 11 Nov 2025
