Datasheet – Self-Clinching, Thin Sheet Metal Standoffs

Supplier: Sucatec

Product type: Self-clinching standoff

Use: Thin sheet metal spacing / stand-offing

Overview

Self-clinching thin sheet metal standoffs provide permanent, high-strength spacing in sheet metal panels where access is limited and traditional hardware is impractical. Once installed, the standoff becomes an integral part of the sheet, providing consistent stand-off height and robust retention.

Key features

Designed for thin sheets where conventional tapped holes or weldments may be unsuitable.
Provides a durable stand-off height for mounting, spacing, and alignment.
Self-clinching installation for strong resistance to push-out and torque (dependent on sheet and installation).

Materials and finishes

Heat-treated steel with zinc clear finish (typical).
Other materials and finishes may be available on request.

Installation guidance

Prepare the panel with the specified hole diameter.
Use a parallel press to install, supporting the sheet appropriately to avoid distortion.
Ensure the recommended minimum edge distance is maintained.

Dimensions & tolerances: Values shown are nominal; tolerances are shown in brackets where provided.

Product table

Thread Size	Thread Style	Type	Material	Finish	Sheet Min.	Hole Diameter	B	L	S Nom.	CL to Edge Min.	CH Min.
#2-56	Full Thread	Unified	Steel, (Heat Treated)	Zinc Clear	0.025	0.166 (+0.003 / -0.000)	0.165 (-0.005)	0.09 (±0.003)	0.187	0.2	0.23
#2-56	Full Thread	Unified	Steel, (Heat Treated)	Zinc Clear	0.025	0.166 (+0.003 / -0.000)	0.165 (-0.005)	0.125 (±0.003)	0.187	0.2	0.23
#2-56	Full Thread	Unified	Steel, (Heat Treated)	Zinc Clear	0.025	0.166 (+0.003 / -0.000)	0.165 (-0.005)	0.187 (±0.003)	0.187	0.2	0.23
#2-56	Full Thread	Unified	Steel, (Heat Treated)	Zinc Clear	0.025	0.166 (+0.003 / -0.000)	0.165 (-0.005)	0.25 (±0.003)	0.187	0.2	0.23
#2-56	Partial Thread	Unified	Steel, (Heat Treated)	Zinc Clear	0.025	0.166 (+0.003 / -0.000)	0.165 (-0.005)	0.312 (±0.003)	0.187	0.2	0.23
#2-56	Partial Thread	Unified	Steel, (Heat Treated)	Zinc Clear	0.025	0.166 (+0.003 / -0.000)	0.165 (-0.005)	0.375 (±0.003)	0.187	0.2	0.23
#2-56	Blind Thread	Unified	Steel, (Heat Treated)	Zinc Clear	0.025	0.166 (+0.003 / -0.000)	0.165 (-0.005)	0.437 (±0.003)	0.187	0.2	0.23
#2-56	Blind Thread	Unified	Steel, (Heat Treated)	Zinc Clear	0.025	0.166 (+0.003 / -0.000)	0.165 (-0.005)	0.5 (±0.003)	0.187	0.2	0.23
#2-56	Blind Thread	Unified	Steel, (Heat Treated)	Zinc Clear	0.025	0.166 (+0.003 / -0.000)	0.165 (-0.005)	0.562 (±0.003)	0.187	0.2	0.23
#2-56	Blind Thread	Unified	Steel, (Heat Treated)	Zinc Clear	0.025	0.166 (+0.003 / -0.000)	0.165 (-0.005)	0.625 (±0.003)	0.187	0.2	0.23
#2-56	Blind Thread	Unified	Steel, (Heat Treated)	Zinc Clear	0.025	0.166 (+0.003 / -0.000)	0.165 (-0.005)	0.687 (±0.003)	0.187	0.2	0.23
#2-56	Blind Thread	Unified	Steel, (Heat Treated)	Zinc Clear	0.025	0.166 (+0.003 / -0.000)	0.165 (-0.005)	0.75 (±0.003)	0.187	0.2	0.23
#4-40	Full Thread	Unified	Steel, (Heat Treated)	Zinc Clear	0.025	0.166 (+0.003 / -0.000)	0.165 (-0.005)	0.09 (±0.003)	0.187	0.22	0.23
#4-40	Full Thread	Unified	Steel, (Heat Treated)	Zinc Clear	0.025	0.166 (+0.003 / -0.000)	0.165 (-0.005)	0.125 (±0.003)	0.187	0.22	0.23
#4-40	Full Thread	Unified	Steel, (Heat Treated)	Zinc Clear	0.025	0.166 (+0.003 / -0.000)	0.165 (-0.005)	0.187 (±0.003)	0.187	0.22	0.23
#4-40	Full Thread	Unified	Steel, (Heat Treated)	Zinc Clear	0.025	0.166 (+0.003 / -0.000)	0.165 (-0.005)	0.25 (±0.003)	0.187	0.22	0.23
#4-40	Partial Thread	Unified	Steel, (Heat Treated)	Zinc Clear	0.025	0.166 (+0.003 / -0.000)	0.165 (-0.005)	0.312 (±0.003)	0.187	0.22	0.23
#4-40	Partial Thread	Unified	Steel, (Heat Treated)	Zinc Clear	0.025	0.166 (+0.003 / -0.000)	0.165 (-0.005)	0.375 (±0.003)	0.187	0.22	0.23
#4-40	Partial Thread	Unified	Steel, (Heat Treated)	Zinc Clear	0.025	0.166 (+0.003 / -0.000)	0.165 (-0.005)	0.437 (±0.003)	0.187	0.22	0.23
#4-40	Blind Thread	Unified	Steel, (Heat Treated)	Zinc Clear	0.025	0.166 (+0.003 / -0.000)	0.165 (-0.005)	0.5 (±0.003)	0.187	0.22	0.23
#4-40	Blind Thread	Unified	Steel, (Heat Treated)	Zinc Clear	0.025	0.166 (+0.003 / -0.000)	0.165 (-0.005)	0.562 (±0.003)	0.187	0.22	0.23
#4-40	Blind Thread	Unified	Steel, (Heat Treated)	Zinc Clear	0.025	0.166 (+0.003 / -0.000)	0.165 (-0.005)	0.625 (±0.003)	0.187	0.22	0.23
#4-40	Blind Thread	Unified	Steel, (Heat Treated)	Zinc Clear	0.025	0.166 (+0.003 / -0.000)	0.165 (-0.005)	0.687 (±0.003)	0.187	0.22	0.23
#4-40	Blind Thread	Unified	Steel, (Heat Treated)	Zinc Clear	0.025	0.166 (+0.003 / -0.000)	0.165 (-0.005)	0.75 (±0.003)	0.187	0.22	0.23
#2-56	Full Thread	Unified	Steel, (Heat Treated)	Zinc Clear	0.025	0.213 (+0.003 / -0.000)	0.212 (-0.005)	0.09 (±0.003)	0.25	0.2	0.27
#2-56	Full Thread	Unified	Steel, (Heat Treated)	Zinc Clear	0.025	0.213 (+0.003 / -0.000)	0.212 (-0.005)	0.125 (±0.003)	0.25	0.2	0.27
#2-56	Full Thread	Unified	Steel, (Heat Treated)	Zinc Clear	0.025	0.213 (+0.003 / -0.000)	0.212 (-0.005)	0.187 (±0.003)	0.25	0.2	0.27
#2-56	Full Thread	Unified	Steel, (Heat Treated)	Zinc Clear	0.025	0.213 (+0.003 / -0.000)	0.212 (-0.005)	0.25 (±0.003)	0.25	0.2	0.27
#2-56	Partial Thread	Unified	Steel, (Heat Treated)	Zinc Clear	0.025	0.213 (+0.003 / -0.000)	0.212 (-0.005)	0.312 (±0.003)	0.25	0.2	0.27
#2-56	Partial Thread	Unified	Steel, (Heat Treated)	Zinc Clear	0.025	0.213 (+0.003 / -0.000)	0.212 (-0.005)	0.375 (±0.003)	0.25	0.2	0.27
#2-56	Blind Thread	Unified	Steel, (Heat Treated)	Zinc Clear	0.025	0.213 (+0.003 / -0.000)	0.212 (-0.005)	0.437 (±0.003)	0.25	0.2	0.27
#2-56	Blind Thread	Unified	Steel, (Heat Treated)	Zinc Clear	0.025	0.213 (+0.003 / -0.000)	0.212 (-0.005)	0.5 (±0.003)	0.25	0.2	0.27
#2-56	Blind Thread	Unified	Steel, (Heat Treated)	Zinc Clear	0.025	0.213 (+0.003 / -0.000)	0.212 (-0.005)	0.562 (±0.003)	0.25	0.2	0.27
#2-56	Blind Thread	Unified	Steel, (Heat Treated)	Zinc Clear	0.025	0.213 (+0.003 / -0.000)	0.212 (-0.005)	0.625 (±0.003)	0.25	0.2	0.27
#2-56	Blind Thread	Unified	Steel, (Heat Treated)	Zinc Clear	0.025	0.213 (+0.003 / -0.000)	0.212 (-0.005)	0.687 (±0.003)	0.25	0.2	0.27
#2-56	Blind Thread	Unified	Steel, (Heat Treated)	Zinc Clear	0.025	0.213 (+0.003 / -0.000)	0.212 (-0.005)	0.75 (±0.003)	0.25	0.2	0.27
#6-32	Full Thread	Unified	Steel, (Heat Treated)	Zinc Clear	0.025	0.213 (+0.003 / -0.000)	0.212 (-0.005)	0.125 (±0.003)	0.25	0.27	0.27
#6-32	Full Thread	Unified	Steel, (Heat Treated)	Zinc Clear	0.025	0.213 (+0.003 / -0.000)	0.212 (-0.005)	0.187 (±0.003)	0.25	0.27	0.27
#6-32	Full Thread	Unified	Steel, (Heat Treated)	Zinc Clear	0.025	0.213 (+0.003 / -0.000)	0.212 (-0.005)	0.25 (±0.003)	0.25	0.27	0.27
#6-32	Full Thread	Unified	Steel, (Heat Treated)	Zinc Clear	0.025	0.213 (+0.003 / -0.000)	0.212 (-0.005)	0.312 (±0.003)	0.25	0.27	0.27
#6-32	Partial Thread	Unified	Steel, (Heat Treated)	Zinc Clear	0.025	0.213 (+0.003 / -0.000)	0.212 (-0.005)	0.375 (±0.003)	0.25	0.27	0.27
#6-32	Partial Thread	Unified	Steel, (Heat Treated)	Zinc Clear	0.025	0.213 (+0.003 / -0.000)	0.212 (-0.005)	0.437 (±0.003)	0.25	0.27	0.27
#6-32	Partial Thread	Unified	Steel, (Heat Treated)	Zinc Clear	0.025	0.213 (+0.003 / -0.000)	0.212 (-0.005)	0.5 (±0.003)	0.25	0.27	0.27
#6-32	Blind Thread	Unified	Steel, (Heat Treated)	Zinc Clear	0.025	0.213 (+0.003 / -0.000)	0.212 (-0.005)	0.562 (±0.003)	0.25	0.27	0.27
#6-32	Blind Thread	Unified	Steel, (Heat Treated)	Zinc Clear	0.025	0.213 (+0.003 / -0.000)	0.212 (-0.005)	0.625 (±0.003)	0.25	0.27	0.27
#6-32	Blind Thread	Unified	Steel, (Heat Treated)	Zinc Clear	0.025	0.213 (+0.003 / -0.000)	0.212 (-0.005)	0.687 (±0.003)	0.25	0.27	0.27
#6-32	Blind Thread	Unified	Steel, (Heat Treated)	Zinc Clear	0.025	0.213 (+0.003 / -0.000)	0.212 (-0.005)	0.75 (±0.003)	0.25	0.27	0.27
#4-40	Full Thread	Unified	Steel, (Heat Treated)	Zinc Clear	0.025	0.213 (+0.003 / -0.000)	0.212 (-0.005)	0.09 (±0.003)	0.25	0.22	0.27
#4-40	Full Thread	Unified	Steel, (Heat Treated)	Zinc Clear	0.025	0.213 (+0.003 / -0.000)	0.212 (-0.005)	0.125 (±0.003)	0.25	0.22	0.27
#4-40 (Thread ; Size)	Full Thread	Unified (Type)	Steel, (Heat Treated ; Material)	Zinc Clear (Finish)	0.025 (Sheet ; Min.)	0.213 (+0.003 / -0.000 ; Hole ; Diameter)	0.212 (-0.005 ; A)	0.187 (±0.003 ; L)	0.25 (H ; Nom.)	0.22 (T ; Min.)	0.27 (CL to Edge ; Min.)
#4-40	Full Thread	Unified	Steel, (Heat Treated)	Zinc Clear	0.025	0.213 (+0.003 / -0.000)	0.212 (-0.005)	0.25 (±0.003)	0.25	0.22	0.27
#4-40 (#4-40)	Partial Thread	Unified (Unified)	Steel, (Heat Treated ; Steel,)	Zinc Clear (Zinc Clear)	0.025 (+0.025)	0.213 (+0.003 / +0.213 / -0.000)	0.212 (+0.212 / -0.005)	0.312 (+0.375 ; ±0.003)	0.25 (+0.25)	0.22 (+0.22)	0.27 (+0.27)
	Partial Thread		Heat Treated			0.003	0 (-0.005)	±0.003
#4-40	Partial Thread	Unified	Steel, (Heat Treated)	Zinc Clear	0.025	0.213 (+0.003 / -0.000)	0.212 (-0.005)	0.437 (±0.003)	0.25	0.22	0.27
#4-40	Blind Thread	Unified	Steel, (Heat Treated)	Zinc Clear	0.025	0.213 (+0.003 / -0.000)	0.212 (-0.005)	0.5 (±0.003)	0.25	0.22	0.27
#4-40	Blind Thread	Unified	Steel, (Heat Treated)	Zinc Clear	0.025	0.213 (+0.003 / -0.000)	0.212 (-0.005)	0.562 (±0.003)	0.25	0.22	0.27
#4-40	Blind Thread	Unified	Steel, (Heat Treated)	Zinc Clear	0.025	0.213 (+0.003 / -0.000)	0.212 (-0.005)	0.625 (±0.003)	0.25	0.22	0.27
#4-40	Blind Thread	Unified	Steel, (Heat Treated)	Zinc Clear	0.025	0.213 (+0.003 / -0.000)	0.212 (-0.005)	0.687 (±0.003)	0.25	0.22	0.27
#4-40	Blind Thread	Unified	Steel, (Heat Treated)	Zinc Clear	0.025	0.213 (+0.003 / -0.000)	0.212 (-0.005)	0.75 (±0.003)	0.25	0.22	0.27
M2.5 x 0.45	Blind Thread	Metric	Steel, (Heat Treated)	Zinc Clear	0.63	5.41 (+0.08 / -0.000)	5.39 (-0.13)	10 (±0.08)	6.4	5.2	7.1
M2.5 x 0.45	Blind Thread	Metric	Steel, (Heat Treated)	Zinc Clear	0.63	5.41 (+0.08 / -0.000)	5.39 (-0.13)	12 (±0.08)	6.4	5.2	7.1
M2.5 x 0.45	Blind Thread	Metric	Steel, (Heat Treated)	Zinc Clear	0.63	5.41 (+0.08 / -0.000)	5.39 (-0.13)	14 (±0.08)	6.4	5.2	7.1
M2.5 x 0.45	Blind Thread	Metric	Steel, (Heat Treated)	Zinc Clear	0.63	5.41 (+0.08 / -0.000)	5.39 (-0.13)	16 (±0.08)	6.4	5.2	7.1
M2.5 x 0.45	Blind Thread	Metric	Steel, (Heat Treated)	Zinc Clear	0.63	5.41 (+0.08 / -0.000)	5.39 (-0.13)	18 (±0.08)	6.4	5.2	7.1
M2.5 x 0.45	Blind Thread	Metric	Steel, (Heat Treated)	Zinc Clear	0.63	5.41 (+0.08 / -0.000)	5.39 (-0.13)	19 (±0.08)	6.4	5.2	7.1
M2.5 x 0.45	Full Thread	Metric	Steel, (Heat Treated)	Zinc Clear	0.63	5.41 (+0.08 / -0.000)	5.39 (-0.13)	2 (±0.08)	6.4	5.2	7.1
M2.5 x 0.45	Full Thread	Metric	Steel, (Heat Treated)	Zinc Clear	0.63	5.41 (+0.08 / -0.000)	5.39 (-0.13)	3 (±0.08)	6.4	5.2	7.1
M2.5 x 0.45	Full Thread	Metric	Steel, (Heat Treated)	Zinc Clear	0.63	5.41 (+0.08 / -0.000)	5.39 (-0.13)	4 (±0.08)	6.4	5.2	7.1
M2.5 x 0.45	Full Thread	Metric	Steel, (Heat Treated)	Zinc Clear	0.63	5.41 (+0.08 / -0.000)	5.39 (-0.13)	6 (±0.08)	6.4	5.2	7.1
M2.5 x 0.45	Partial Thread	Metric	Steel, (Heat Treated)	Zinc Clear	0.63	5.41 (+0.08 / -0.000)	5.39 (-0.13)	8 (±0.08)	6.4	5.2	7.1
M3 x 0.5	Partial Thread	Metric	Steel, (Heat Treated)	Zinc Clear	0.63	5.41 (+0.08 / -0.000)	5.39 (-0.13)	10 (±0.08)	6.4	6.2	7.1
M3 x 0.5	Blind Thread	Metric	Steel, (Heat Treated)	Zinc Clear	0.63	5.41 (+0.08 / -0.000)	5.39 (-0.13)	12 (±0.08)	6.4	6.2	7.1
M3 x 0.5	Blind Thread	Metric	Steel, (Heat Treated)	Zinc Clear	0.63	5.41 (+0.08 / -0.000)	5.39 (-0.13)	14 (±0.08)	6.4	6.2	7.1
M3 x 0.5	Blind Thread	Metric	Steel, (Heat Treated)	Zinc Clear	0.63	5.41 (+0.08 / -0.000)	5.39 (-0.13)	16 (±0.08)	6.4	6.2	7.1
M3 x 0.5	Blind Thread	Metric	Steel, (Heat Treated)	Zinc Clear	0.63	5.41 (+0.08 / -0.000)	5.39 (-0.13)	18 (±0.08)	6.4	6.2	7.1
M3 x 0.5	Blind Thread	Metric	Steel, (Heat Treated)	Zinc Clear	0.63	5.41 (+0.08 / -0.000)	5.39 (-0.13)	19 (±0.08)	6.4	6.2	7.1
M3 x 0.5	Full Thread	Metric	Steel, (Heat Treated)	Zinc Clear	0.63	5.41 (+0.08 / -0.000)	5.39 (-0.13)	2 (±0.08)	6.4	6.2	7.1
M3 x 0.5	Full Thread	Metric	Steel, (Heat Treated)	Zinc Clear	0.63	5.41 (+0.08 / -0.000)	5.39 (-0.13)	3 (±0.08)	6.4	6.2	7.1
M3 x 0.5	Full Thread	Metric	Steel, (Heat Treated)	Zinc Clear	0.63	5.41 (+0.08 / -0.000)	5.39 (-0.13)	4 (±0.08)	6.4	6.2	7.1
M3 x 0.5	Full Thread	Metric	Steel, (Heat Treated)	Zinc Clear	0.63	5.41 (+0.08 / -0.000)	5.39 (-0.13)	6 (±0.08)	6.4	6.2	7.1
M3 x 0.5	Partial Thread	Metric	Steel, (Heat Treated)	Zinc Clear	0.63	5.41 (+0.08 / -0.000)	5.39 (-0.13)	8 (±0.08)	6.4	6.2	7.1
#2-56	Full Thread	Unified	Aluminum, (7076-T6)	None	0.025	0.166 (+0.003 / -0.000)	0.165 (-0.005)	0.09 (±0.003)	0.187	0.2	0.23
#2-56	Full Thread	Unified	Aluminum, (7076-T6)	None	0.025	0.166 (+0.003 / -0.000)	0.165 (-0.005)	0.125 (±0.003)	0.187	0.2	0.23
#2-56	Full Thread	Unified	Aluminum, (7076-T6)	None	0.025	0.166 (+0.003 / -0.000)	0.165 (-0.005)	0.187 (±0.003)	0.187	0.2	0.23
#2-56	Full Thread	Unified	Aluminum, (7076-T6)	None	0.025	0.166 (+0.003 / -0.000)	0.165 (-0.005)	0.25 (±0.003)	0.187	0.2	0.23
#2-56	Partial Thread	Unified	Aluminum, (7076-T6)	None	0.025	0.166 (+0.003 / -0.000)	0.165 (-0.005)	0.312 (±0.003)	0.187	0.2	0.23
#2-56	Partial Thread	Unified	Aluminum, (7076-T6)	None	0.025	0.166 (+0.003 / -0.000)	0.165 (-0.005)	0.375 (±0.003)	0.187	0.2	0.23
#2-56	Blind Thread	Unified	Aluminum, (7076-T6)	None	0.025	0.166 (+0.003 / -0.000)	0.165 (-0.005)	0.437 (±0.003)	0.187	0.2	0.23
#2-56	Blind Thread	Unified	Aluminum, (7076-T6)	None	0.025	0.166 (+0.003 / -0.000)	0.165 (-0.005)	0.5 (±0.003)	0.187	0.2	0.23
#2-56	Blind Thread	Unified	Aluminum, (7076-T6)	None	0.025	0.166 (+0.003 / -0.000)	0.165 (-0.005)	0.562 (±0.003)	0.187	0.2	0.23
#2-56	Blind Thread	Unified	Aluminum, (7076-T6)	None	0.025	0.166 (+0.003 / -0.000)	0.165 (-0.005)	0.625 (±0.003)	0.187	0.2	0.23
#2-56	Blind Thread	Unified	Aluminum, (7076-T6)	None	0.025	0.166 (+0.003 / -0.000)	0.165 (-0.005)	0.687 (±0.003)	0.187	0.2	0.23
#2-56	Blind Thread	Unified	Aluminum, (7076-T6)	None	0.025	0.166 (+0.003 / -0.000)	0.165 (-0.005)	0.75 (±0.003)	0.187	0.2	0.23
#4-40	Full Thread	Unified	Aluminum, (7076-T6)	None	0.025	0.166 (+0.003 / -0.000)	0.165 (-0.005)	0.09 (±0.003)	0.187	0.22	0.23
#4-40	Full Thread	Unified	Aluminum, (7076-T6)	None	0.025	0.166 (+0.003 / -0.000)	0.165 (-0.005)	0.125 (±0.003)	0.187	0.22	0.23
#4-40	Full Thread	Unified	Aluminum, (7076-T6)	None	0.025	0.166 (+0.003 / -0.000)	0.165 (-0.005)	0.187 (±0.003)	0.187	0.22	0.23
#4-40	Full Thread	Unified	Aluminum, (7076-T6)	None	0.025	0.166 (+0.003 / -0.000)	0.165 (-0.005)	0.25 (±0.003)	0.187	0.22	0.23
#4-40	Partial Thread	Unified	Aluminum, (7076-T6)	None	0.025	0.166 (+0.003 / -0.000)	0.165 (-0.005)	0.312 (±0.003)	0.187	0.22	0.23
#4-40	Partial Thread	Unified	Aluminum, (7076-T6)	None	0.025	0.166 (+0.003 / -0.000)	0.165 (-0.005)	0.375 (±0.003)	0.187	0.22	0.23
#4-40 (Thread ; Size)	Partial Thread	Unified (Type)	Aluminum, (7076-T6 ; Material)	None (Finish)	0.025 (Sheet ; Min.)	0.166 (+0.003 / -0.000 ; Hole ; Diameter)	0.165 (-0.005 ; A)	0.437 (±0.003 ; L)	0.187 (H ; Nom.)	0.22 (T ; Min.)	0.23 (CL to Edge ; Min.)
#4-40	Blind Thread	Unified	Aluminum, (7076-T6)	None	0.025	0.166 (+0.003 / -0.000)	0.165 (-0.005)	0.5 (±0.003)	0.187	0.22	0.23
#4-40	Blind Thread	Unified	Aluminum, (7076-T6)	None	0.025	0.166 (+0.003 / -0.000)	0.165 (-0.005)	0.562 (±0.003)	0.187	0.22	0.23
#4-40	Blind Thread	Unified	Aluminum, (7076-T6)	None	0.025	0.166 (+0.003 / -0.000)	0.165 (-0.005)	0.625 (±0.003)	0.187	0.22	0.23
#4-40	Blind Thread	Unified	Aluminum, (7076-T6)	None	0.025	0.166 (+0.003 / -0.000)	0.165 (-0.005)	0.687 (±0.003)	0.187	0.22	0.23
#4-40	Blind Thread	Unified	Aluminum, (7076-T6)	None	0.025	0.166 (+0.003 / -0.000)	0.165 (-0.005)	0.75 (±0.003)	0.187	0.22	0.23
#2-56	Full Thread	Unified	Aluminum, (7076-T6)	None	0.025	0.213 (+0.003 / -0.000)	0.212 (-0.005)	0.09 (±0.003)	0.25	0.2	0.27
#2-56	Full Thread	Unified	Aluminum, (7076-T6)	None	0.025	0.213 (+0.003 / -0.000)	0.212 (-0.005)	0.125 (±0.003)	0.25	0.2	0.27
#2-56	Full Thread	Unified	Aluminum, (7076-T6)	None	0.025	0.213 (+0.003 / -0.000)	0.212 (-0.005)	0.187 (±0.003)	0.25	0.2	0.27
#2-56	Full Thread	Unified	Aluminum, (7076-T6)	None	0.025	0.213 (+0.003 / -0.000)	0.212 (-0.005)	0.25 (±0.003)	0.25	0.2	0.27
#2-56	Partial Thread	Unified	Aluminum, (7076-T6)	None	0.025	0.213 (+0.003 / -0.000)	0.212 (-0.005)	0.312 (±0.003)	0.25	0.2	0.27
#2-56	Partial Thread	Unified	Aluminum, (7076-T6)	None	0.025	0.213 (+0.003 / -0.000)	0.212 (-0.005)	0.375 (±0.003)	0.25	0.2	0.27
#2-56	Blind Thread	Unified	Aluminum, (7076-T6)	None	0.025	0.213 (+0.003 / -0.000)	0.212 (-0.005)	0.437 (±0.003)	0.25	0.2	0.27
#2-56	Blind Thread	Unified	Aluminum, (7076-T6)	None	0.025	0.213 (+0.003 / -0.000)	0.212 (-0.005)	0.5 (±0.003)	0.25	0.2	0.27
#2-56	Blind Thread	Unified	Aluminum, (7076-T6)	None	0.025	0.213 (+0.003 / -0.000)	0.212 (-0.005)	0.562 (±0.003)	0.25	0.2	0.27
#2-56	Blind Thread	Unified	Aluminum, (7076-T6)	None	0.025	0.213 (+0.003 / -0.000)	0.212 (-0.005)	0.625 (±0.003)	0.25	0.2	0.27
#2-56	Blind Thread	Unified	Aluminum, (7076-T6)	None	0.025	0.213 (+0.003 / -0.000)	0.212 (-0.005)	0.687 (±0.003)	0.25	0.2	0.27
#2-56	Blind Thread	Unified	Aluminum, (7076-T6)	None	0.025	0.213 (+0.003 / -0.000)	0.212 (-0.005)	0.75 (±0.003)	0.25	0.2	0.27
#6-32	Full Thread	Unified	Aluminum, (7076-T6)	None	0.025	0.213 (+0.003 / -0.000)	0.212 (-0.005)	0.125 (±0.003)	0.25	0.27	0.27
#6-32	Full Thread	Unified	Aluminum, (7076-T6)	None	0.025	0.213 (+0.003 / -0.000)	0.212 (-0.005)	0.187 (±0.003)	0.25	0.27	0.27
#6-32	Full Thread	Unified	Aluminum, (7076-T6)	None	0.025	0.213 (+0.003 / -0.000)	0.212 (-0.005)	0.25 (±0.003)	0.25	0.27	0.27
#6-32	Full Thread	Unified	Aluminum, (7076-T6)	None	0.025	0.213 (+0.003 / -0.000)	0.212 (-0.005)	0.312 (±0.003)	0.25	0.27	0.27
#6-32	Partial Thread	Unified	Aluminum, (7076-T6)	None	0.025	0.213 (+0.003 / -0.000)	0.212 (-0.005)	0.375 (±0.003)	0.25	0.27	0.27
#6-32	Partial Thread	Unified	Aluminum, (7076-T6)	None	0.025	0.213 (+0.003 / -0.000)	0.212 (-0.005)	0.437 (±0.003)	0.25	0.27	0.27
#6-32	Partial Thread	Unified	Aluminum, (7076-T6)	None	0.025	0.213 (+0.003 / -0.000)	0.212 (-0.005)	0.5 (±0.003)	0.25	0.27	0.27
#6-32	Blind Thread	Unified	Aluminum, (7076-T6)	None	0.025	0.213 (+0.003 / -0.000)	0.212 (-0.005)	0.562 (±0.003)	0.25	0.27	0.27
#6-32	Blind Thread	Unified	Aluminum, (7076-T6)	None	0.025	0.213 (+0.003 / -0.000)	0.212 (-0.005)	0.625 (±0.003)	0.25	0.27	0.27
#6-32	Blind Thread	Unified	Aluminum, (7076-T6)	None	0.025	0.213 (+0.003 / -0.000)	0.212 (-0.005)	0.687 (±0.003)	0.25	0.27	0.27
#6-32	Blind Thread	Unified	Aluminum, (7076-T6)	None	0.025	0.213 (+0.003 / -0.000)	0.212 (-0.005)	0.75 (±0.003)	0.25	0.27	0.27
#4-40	Full Thread	Unified	Aluminum, (7076-T6)	None	0.025	0.213 (+0.003)	0.212 (-0.005)	0.09 (±0.003)	0.25	0.22	0.27
#4-40	Full Thread	Unified	Aluminum, (7076-T6)	None	0.025	0.213 (+0.003 / -0.000)	0.212 (-0.005)	0.125 (±0.003)	0.25	0.22	0.27
#4-40	Full Thread	Unified	Aluminum, (7076-T6)	None	0.025	0.213 (+0.003 / -0.000)	0.212 (-0.005)	0.187 (±0.003)	0.25	0.22	0.27
#4-40	Full Thread	Unified	Aluminum, (7076-T6)	None	0.025	0.213 (+0.003 / -0.000)	0.212 (-0.005)	0.25 (±0.003)	0.25	0.22	0.27
#4-40	Partial Thread	Unified	Aluminum, (7076-T6)	None	0.025	0.213 (+0.003 / -0.000)	0.212 (-0.005)	0.312 (±0.003)	0.25	0.22	0.27
#4-40	Partial Thread	Unified	Aluminum, (7076-T6)	None	0.025	0.213 (+0.003 / -0.000)	0.212 (-0.005)	0.375 (±0.003)	0.25	0.22	0.27
#4-40	Partial Thread	Unified	Aluminum, (7076-T6)	None	0.025	0.213 (+0.003 / -0.000)	0.212 (-0.005)	0.437 (±0.003)	0.25	0.22	0.27
#4-40	Blind Thread	Unified	Aluminum, (7076-T6)	None	0.025	0.213 (+0.003 / -0.000)	0.212 (-0.005)	0.5 (±0.003)	0.25	0.22	0.27
#4-40	Blind Thread	Unified	Aluminum, (7076-T6)	None	0.025	0.213 (+0.003 / -0.000)	0.212 (-0.005)	0.562 (±0.003)	0.25	0.22	0.27
#4-40	Blind Thread	Unified	Aluminum, (7076-T6)	None	0.025	0.213 (+0.003 / -0.000)	0.212 (-0.005)	0.625 (±0.003)	0.25	0.22	0.27
#4-40	Blind Thread	Unified	Aluminum, (7076-T6)	None	0.025	0.213 (+0.003 / -0.000)	0.212 (-0.005)	0.687 (±0.003)	0.25	0.22	0.27
#4-40	Blind Thread	Unified	Aluminum, (7076-T6)	None	0.025	0.213 (+0.003 / -0.000)	0.212 (-0.005)	0.75 (±0.003)	0.25	0.22	0.27
M2.5 x 0.45	Blind Thread	Metric	Aluminum, (7076-T6)	None	0.63	5.41 (+0.08 / -0.000)	5.39 (-0.13)	10 (±0.08)	6.4	5.2	7.1
M2.5 x 0.45	Blind Thread	Metric	Aluminum, (7076-T6)	None	0.63	5.41 (+0.08 / -0.000)	5.39 (-0.13)	12 (±0.08)	6.4	5.2	7.1
M2.5 x 0.45	Blind Thread	Metric	Aluminum, (7076-T6)	None	0.63	5.41 (+0.08 / -0.000)	5.39 (-0.13)	14 (±0.08)	6.4	5.2	7.1
M2.5 x 0.45	Blind Thread	Metric	Aluminum, (7076-T6)	None	0.63	5.41 (+0.08 / -0.000)	5.39 (-0.13)	16 (±0.08)	6.4	5.2	7.1
M2.5 x 0.45	Blind Thread	Metric	Aluminum, (7076-T6)	None	0.63	5.41 (+0.08 / -0.000)	5.39 (-0.13)	18 (±0.08)	6.4	5.2	7.1
M2.5 x 0.45	Blind Thread	Metric	Aluminum, (7076-T6)	None	0.63	5.41 (+0.08 / -0.000)	5.39 (-0.13)	19 (±0.08)	6.4	5.2	7.1
M2.5 x 0.45	Full Thread	Metric	Aluminum, (7076-T6)	None	0.63	5.41 (+0.08 / -0.000)	5.39 (-0.13)	2 (±0.08)	6.4	5.2	7.1
M2.5 x 0.45	Full Thread	Metric	Aluminum, (7076-T6)	None	0.63	5.41 (+0.08 / -0.000)	5.39 (-0.13)	3 (±0.08)	6.4	5.2	7.1
M2.5 x 0.45	Full Thread	Metric	Aluminum, (7076-T6)	None	0.63	5.41 (+0.08 / -0.000)	5.39 (-0.13)	4 (±0.08)	6.4	5.2	7.1
M2.5 x 0.45 (Thread ; Size)	Full Thread	Metric (Type)	Aluminum, (7076-T6 ; Material)	None (Finish)	0.63 (Sheet ; Min.)	5.41 (+0.08 / -0.000 ; Hole ; Diameter)	5.39 (-0.13 ; A)	6 (±0.08 ; L)	6.4 (H ; Nom.)	5.2 (T ; Min.)	7.1 (CL to Edge ; Min.)
M2.5 x 0.45	Partial Thread	Metric	Aluminum, (7076-T6)	None	0.63	5.41 (+0.08 / -0.000)	5.39 (-0.13)	8 (±0.08)	6.4	5.2	7.1
M3 x 0.5	Partial Thread	Metric	Aluminum, (7076-T6)	None	0.63	5.41 (+0.08 / -0.000)	5.39 (-0.13)	10 (±0.08)	6.4	6.2	7.1
M3 x 0.5	Blind Thread	Metric	Aluminum, (7076-T6)	None	0.63	5.41 (+0.08 / -0.000)	5.39 (-0.13)	12 (±0.08)	6.4	6.2	7.1
M3 x 0.5	Blind Thread	Metric	Aluminum, (7076-T6)	None	0.63	5.41 (+0.08 / -0.000)	5.39 (-0.13)	14 (±0.08)	6.4	6.2	7.1
M3 x 0.5	Blind Thread	Metric	Aluminum, (7076-T6)	None	0.63	5.41 (+0.08 / -0.000)	5.39 (-0.13)	16 (±0.08)	6.4	6.2	7.1
M3 x 0.5	Blind Thread	Metric	Aluminum, (7076-T6)	None	0.63	5.41 (+0.08 / -0.000)	5.39 (-0.13)	18 (±0.08)	6.4	6.2	7.1
M3 x 0.5	Blind Thread	Metric	Aluminum, (7076-T6)	None	0.63	5.41 (+0.08 / -0.000)	5.39 (-0.13)	19 (±0.08)	6.4	6.2	7.1
M3 x 0.5	Full Thread	Metric	Aluminum, (7076-T6)	None	0.63	5.41 (+0.08 / -0.000)	5.39 (-0.13)	2 (±0.08)	6.4	6.2	7.1
M3 x 0.5	Full Thread	Metric	Aluminum, (7076-T6)	None	0.63	5.41 (+0.08 / -0.000)	5.39 (-0.13)	3 (±0.08)	6.4	6.2	7.1
M3 x 0.5	Full Thread	Metric	Aluminum, (7076-T6)	None	0.63	5.41 (+0.08 / -0.000)	5.39 (-0.13)	4 (±0.08)	6.4	6.2	7.1
M3 x 0.5	Full Thread	Metric	Aluminum, (7076-T6)	None	0.63	5.41 (+0.08 / -0.000)	5.39 (-0.13)	6 (±0.08)	6.4	6.2	7.1
M3 x 0.5	Partial Thread	Metric	Aluminum, (7076-T6)	None	0.63	5.41 (+0.08 / -0.000)	5.39 (-0.13)	8 (±0.08)	6.4	6.2	7.1
M2.5 x 0.45	Blind Thread	Metric	Aluminum, (7076-T6)	None	0.63	4.22 (+0.08 / -0.000)	4.2 (-0.13)	10 (±0.08)	4.8	5.2	5.8
M2.5 x 0.45	Blind Thread	Metric	Aluminum, (7076-T6)	None	0.63	4.22 (+0.08 / -0.000)	4.2 (-0.13)	12 (±0.08)	4.8	5.2	5.8
M2.5 x 0.45	Blind Thread	Metric	Aluminum, (7076-T6)	None	0.63	4.22 (+0.08 / -0.000)	4.2 (-0.13)	14 (±0.08)	4.8	5.2	5.8
M2.5 x 0.45	Blind Thread	Metric	Aluminum, (7076-T6)	None	0.63	4.22 (+0.08 / -0.000)	4.2 (-0.13)	16 (±0.08)	4.8	5.2	5.8
M2.5 x 0.45	Blind Thread	Metric	Aluminum, (7076-T6)	None	0.63	4.22 (+0.08 / -0.000)	4.2 (-0.13)	18 (±0.08)	4.8	5.2	5.8
M2.5 x 0.45	Blind Thread	Metric	Aluminum, (7076-T6)	None	0.63	4.22 (+0.08 / -0.000)	4.2 (-0.13)	19 (±0.08)	4.8	5.2	5.8
M2.5 x 0.45	Full Thread	Metric	Aluminum, (7076-T6)	None	0.63	4.22 (+0.08 / -0.000)	4.2 (-0.13)	2 (±0.08)	4.8	5.2	5.8
M2.5 x 0.45	Full Thread	Metric	Aluminum, (7076-T6)	None	0.63	4.22 (+0.08 / -0.000)	4.2 (-0.13)	3 (±0.08)	4.8	5.2	5.8
M2.5 x 0.45	Full Thread	Metric	Aluminum, (7076-T6)	None	0.63	4.22 (+0.08 / -0.000)	4.2 (-0.13)	4 (±0.08)	4.8	5.2	5.8
M2.5 x 0.45	Full Thread	Metric	Aluminum, (7076-T6)	None	0.63	4.22 (+0.08 / -0.000)	4.2 (-0.13)	6 (±0.08)	4.8	5.2	5.8
M2.5 x 0.45	Partial Thread	Metric	Aluminum, (7076-T6)	None	0.63	4.22 (+0.08 / -0.000)	4.2 (-0.13)	8 (±0.08)	4.8	5.2	5.8
M3 x 0.5	Partial Thread	Metric	Aluminum, (7076-T6)	None	0.63	4.22 (+0.08 / -0.000)	4.2 (-0.13)	10 (±0.08)	4.8	6.2	5.8
M3 x 0.5	Blind Thread	Metric	Aluminum, (7076-T6)	None	0.63	4.22 (+0.08 / -0.000)	4.2 (-0.13)	12 (±0.08)	4.8	6.2	5.8
M3 x 0.5	Blind Thread	Metric	Aluminum, (7076-T6)	None	0.63	4.22 (+0.08 / -0.000)	4.2 (-0.13)	14 (±0.08)	4.8	6.2	5.8
M3 x 0.5	Blind Thread	Metric	Aluminum, (7076-T6)	None	0.63	4.22 (+0.08 / -0.000)	4.2 (-0.13)	16 (±0.08)	4.8	6.2	5.8
M3 x 0.5	Blind Thread	Metric	Aluminum, (7076-T6)	None	0.63	4.22 (+0.08 / -0.000)	4.2 (-0.13)	18 (±0.08)	4.8	6.2	5.8
M3 x 0.5	Blind Thread	Metric	Aluminum, (7076-T6)	None	0.63	4.22 (+0.08 / -0.000)	4.2 (-0.13)	19 (±0.08)	4.8	6.2	5.8
M3 x 0.5	Full Thread	Metric	Aluminum, (7076-T6)	None	0.63	4.22 (+0.08 / -0.000)	4.2 (-0.13)	2 (±0.08)	4.8	6.2	5.8
M3 x 0.5	Full Thread	Metric	Aluminum, (7076-T6)	None	0.63	4.22 (+0.08 / -0.000)	4.2 (-0.13)	3 (±0.08)	4.8	6.2	5.8
M3 x 0.5	Full Thread	Metric	Aluminum, (7076-T6)	None	0.63	4.22 (+0.08 / -0.000)	4.2 (-0.13)	4 (±0.08)	4.8	6.2	5.8
M3 x 0.5	Full Thread	Metric	Aluminum, (7076-T6)	None	0.63	4.22 (+0.08 / -0.000)	4.2 (-0.13)	6 (±0.08)	4.8	6.2	5.8
M3 x 0.5	Partial Thread	Metric	Aluminum, (7076-T6)	None	0.63	4.22 (+0.08 / -0.000)	4.2 (-0.13)	8 (±0.08)	4.8	6.2	5.8
M3.5 x 0.5	Partial Thread	Metric	Aluminum, (7076-T6)	None	0.63	5.41 (+0.08 / -0.000)	5.39 (-0.13)	10 (±0.08)	6.4	7	7.1
M3.5 x 0.5	Partial Thread	Metric	Aluminum, (7076-T6)	None	0.63	5.41 (+0.08 / -0.000)	5.39 (-0.13)	12 (±0.08)	6.4	7	7.1
M3.5 x 0.5	Blind Thread	Metric	Aluminum, (7076-T6)	None	0.63	5.41 (+0.08 / -0.000)	5.39 (-0.13)	14 (±0.08)	6.4	7	7.1
M3.5 x 0.5	Blind Thread	Metric	Aluminum, (7076-T6)	None	0.63	5.41 (+0.08 / -0.000)	5.39 (-0.13)	16 (±0.08)	6.4	7	7.1
M3.5 x 0.5	Blind Thread	Metric	Aluminum, (7076-T6)	None	0.63	5.41 (+0.08 / -0.000)	5.39 (-0.13)	18 (±0.08)	6.4	7	7.1
M3.5 x 0.5	Blind Thread	Metric	Aluminum, (7076-T6)	None	0.63	5.41 (+0.08 / -0.000)	5.39 (-0.13)	19 (±0.08)	6.4	7	7.1
M3.5 x 0.5	Full Thread	Metric	Aluminum, (7076-T6)	None	0.63	5.41 (+0.08 / -0.000)	5.39 (-0.13)	3 (±0.08)	6.4	7	7.1
M3.5 x 0.5	Full Thread	Metric	Aluminum, (7076-T6)	None	0.63	5.41 (+0.08 / -0.000)	5.39 (-0.13)	4 (±0.08)	6.4	7	7.1
M3.5 x 0.5	Full Thread	Metric	Aluminum, (7076-T6)	None	0.63	5.41 (+0.08 / -0.000)	5.39 (-0.13)	6 (±0.08)	6.4	7	7.1
M3.5 x 0.5	Full Thread	Metric	Aluminum, (7076-T6)	None	0.63	5.41 (+0.08 / -0.000)	5.39 (-0.13)	8 (±0.08)	6.4	7	7.1
M2.5 x 0.45	Blind Thread	Metric	Steel, (Heat Treated)	Zinc Clear	0.63	4.22 (+0.08 / -0.000)	4.2 (-0.13)	10 (±0.08)	4.8	5.2	5.8
M2.5 x 0.45	Blind Thread	Metric	Steel, (Heat Treated)	Zinc Clear	0.63	4.22 (+0.08 / -0.000)	4.2 (-0.13)	12 (±0.08)	4.8	5.2	5.8
M2.5 x 0.45	Blind Thread	Metric	Steel, (Heat Treated)	Zinc Clear	0.63	4.22 (+0.08 / -0.000)	4.2 (-0.13)	14 (±0.08)	4.8	5.2	5.8
M2.5 x 0.45	Blind Thread	Metric	Steel, (Heat Treated)	Zinc Clear	0.63	4.22 (+0.08 / -0.000)	4.2 (-0.13)	16 (±0.08)	4.8	5.2	5.8
M2.5 x 0.45 (M2.5 x 0.45)	Blind Thread	Metric (Metric)	Steel, (Heat Treated ; Steel,)	Zinc Clear (Zinc Clear)	0.63 (+0.63)	4.22 (+0.08 / +4.22 / -0.000)	4.2 (+4.2 / -0.13)	18 (+19 ; ±0.08)	4.8 (+4.8)	5.2 (+5.2)	5.8 (+5.8)
(Thread ; Size)	Blind Thread	(Type)	Heat Treated (Material)	(Finish)	(Sheet ; Min.)	0.08 (Hole ; Diameter)	0 (-0.13 ; A)	±0.08 (L)	(H ; Nom.)	(T ; Min.)	(CL to Edge ; Min.)
M2.5 x 0.45	Full Thread	Metric	Steel, (Heat Treated)	Zinc Clear	0.63	4.22 (+0.08 / -0.000)	4.2 (-0.13)	2 (±0.08)	4.8	5.2	5.8
M2.5 x 0.45	Full Thread	Metric	Steel, (Heat Treated)	Zinc Clear	0.63	4.22 (+0.08 / -0.000)	4.2 (-0.13)	3 (±0.08)	4.8	5.2	5.8
M2.5 x 0.45	Full Thread	Metric	Steel, (Heat Treated)	Zinc Clear	0.63	4.22 (+0.08 / -0.000)	4.2 (-0.13)	4 (±0.08)	4.8	5.2	5.8
M2.5 x 0.45	Full Thread	Metric	Steel, (Heat Treated)	Zinc Clear	0.63	4.22 (+0.08 / -0.000)	4.2 (-0.13)	6 (±0.08)	4.8	5.2	5.8
M2.5 x 0.45	Partial Thread	Metric	Steel, (Heat Treated)	Zinc Clear	0.63	4.22 (+0.08 / -0.000)	4.2 (-0.13)	8 (±0.08)	4.8	5.2	5.8
M3 x 0.5	Blind Thread	Metric	Steel, (Heat Treated)	Zinc Clear	0.63	4.22 (+0.08 / -0.000)	4.2 (-0.13)	10 (±0.08)	4.8	6.2	5.8
M3 x 0.5	Blind Thread	Metric	Steel, (Heat Treated)	Zinc Clear	0.63	4.22 (+0.08 / -0.000)	4.2 (-0.13)	12 (±0.08)	4.8	6.2	5.8
M3 x 0.5	Blind Thread	Metric	Steel, (Heat Treated)	Zinc Clear	0.63	4.22 (+0.08 / -0.000)	4.2 (-0.13)	14 (±0.08)	4.8	6.2	5.8
M3 x 0.5	Blind Thread	Metric	Steel, (Heat Treated)	Zinc Clear	0.63	4.22 (+0.08 / -0.000)	4.2 (-0.13)	16 (±0.08)	4.8	6.2	5.8
M3 x 0.5	Blind Thread	Metric	Steel, (Heat Treated)	Zinc Clear	0.63	4.22 (+0.08 / -0.000)	4.2 (-0.13)	18 (±0.08)	4.8	6.2	5.8
M3 x 0.5	Blind Thread	Metric	Steel, (Heat Treated)	Zinc Clear	0.63	4.22 (+0.08 / -0.000)	4.2 (-0.13)	19 (±0.08)	4.8	6.2	5.8
M3 x 0.5	Full Thread	Metric	Steel, (Heat Treated)	Zinc Clear	0.63	4.22 (+0.08 / -0.000)	4.2 (-0.13)	2 (±0.08)	4.8	6.2	5.8
M3 x 0.5	Full Thread	Metric	Steel, (Heat Treated)	Zinc Clear	0.63	4.22 (+0.08 / -0.000)	4.2 (-0.13)	3 (±0.08)	4.8	6.2	5.8
M3 x 0.5	Full Thread	Metric	Steel, (Heat Treated)	Zinc Clear	0.63	4.22 (+0.08 / -0.000)	4.2 (-0.13)	4 (±0.08)	4.8	6.2	5.8
M3 x 0.5	Full Thread	Metric	Steel, (Heat Treated)	Zinc Clear	0.63	4.22 (+0.08 / -0.000)	4.2 (-0.13)	6 (±0.08)	4.8	6.2	5.8
M3 x 0.5	Partial Thread	Metric	Steel, (Heat Treated)	Zinc Clear	0.63	4.22 (+0.08 / -0.000)	4.2 (-0.13)	8 (±0.08)	4.8	6.2	5.8
M3.5 x 0.5	Blind Thread	Metric	Steel, (Heat Treated)	Zinc Clear	0.63	5.41 (+0.08 / -0.000)	5.39 (-0.13)	10 (±0.08)	6.4	7	7.1
M3.5 x 0.5	Blind Thread	Metric	Steel, (Heat Treated)	Zinc Clear	0.63	5.41 (+0.08 / -0.000)	5.39 (-0.13)	12 (±0.08)	6.4	7	7.1
M3.5 x 0.5	Blind Thread	Metric	Steel, (Heat Treated)	Zinc Clear	0.63	5.41 (+0.08 / -0.000)	5.39 (-0.13)	14 (±0.08)	6.4	7	7.1
M3.5 x 0.5	Blind Thread	Metric	Steel, (Heat Treated)	Zinc Clear	0.63	5.41 (+0.08 / -0.000)	5.39 (-0.13)	16 (±0.08)	6.4	7	7.1
M3.5 x 0.5	Blind Thread	Metric	Steel, (Heat Treated)	Zinc Clear	0.63	5.41 (+0.08 / -0.000)	5.39 (-0.13)	18 (±0.08)	6.4	7	7.1
M3.5 x 0.5	Blind Thread	Metric	Steel, (Heat Treated)	Zinc Clear	0.63	5.41 (+0.08 / -0.000)	5.39 (-0.13)	19 (±0.08)	6.4	7	7.1
M3.5 x 0.5	Full Thread	Metric	Steel, (Heat Treated)	Zinc Clear	0.63	5.41 (+0.08 / -0.000)	5.39 (-0.13)	3 (±0.08)	6.4	7	7.1
M3.5 x 0.5	Full Thread	Metric	Steel, (Heat Treated)	Zinc Clear	0.63	5.41 (+0.08 / -0.000)	5.39 (-0.13)	4 (±0.08)	6.4	7	7.1
M3.5 x 0.5	Full Thread	Metric	Steel, (Heat Treated)	Zinc Clear	0.63	5.41 (+0.08 / -0.000)	5.39 (-0.13)	6 (±0.08)	6.4	7	7.1
M3.5 x 0.5	Full Thread	Metric	Steel, (Heat Treated)	Zinc Clear	0.63	5.41 (+0.08 / -0.000)	5.39 (-0.13)	8 (±0.08)	6.4	7	7.1
#2-56	Full Thread	Unified	Stainless Steel, (300 Series)	Passivated	0.025	0.166 (+0.003 / -0.000)	0.165 (-0.005)	0.09 (±0.003)	0.187	0.2	0.23
#2-56	Full Thread	Unified	Stainless Steel, (300 Series)	Passivated	0.025	0.166 (+0.003 / -0.000)	0.165 (-0.005)	0.125 (±0.003)	0.187	0.2	0.23
#2-56	Full Thread	Unified	Stainless Steel, (300 Series)	Passivated	0.025	0.166 (+0.003 / -0.000)	0.165 (-0.005)	0.187 (±0.003)	0.187	0.2	0.23
#2-56	Full Thread	Unified	Stainless Steel, (300 Series)	Passivated	0.025	0.166 (+0.003 / -0.000)	0.165 (-0.005)	0.25 (±0.003)	0.187	0.2	0.23
#2-56	Partial Thread	Unified	Stainless Steel, (300 Series)	Passivated	0.025	0.166 (+0.003 / -0.000)	0.165 (-0.005)	0.312 (±0.003)	0.187	0.2	0.23
#2-56	Partial Thread	Unified	Stainless Steel, (300 Series)	Passivated	0.025	0.166 (+0.003 / -0.000)	0.165 (-0.005)	0.375 (±0.003)	0.187	0.2	0.23
#2-56	Blind Thread	Unified	Stainless Steel, (300 Series)	Passivated	0.025	0.166 (+0.003 / -0.000)	0.165 (-0.005)	0.437 (±0.003)	0.187	0.2	0.23
#2-56	Blind Thread	Unified	Stainless Steel, (300 Series)	Passivated	0.025	0.166 (+0.003 / -0.000)	0.165 (-0.005)	0.5 (±0.003)	0.187	0.2	0.23
#2-56	Blind Thread	Unified	Stainless Steel, (300 Series)	Passivated	0.025	0.166 (+0.003 / -0.000)	0.165 (-0.005)	0.562 (±0.003)	0.187	0.2	0.23
#2-56	Blind Thread	Unified	Stainless Steel, (300 Series)	Passivated	0.025	0.166 (+0.003 / -0.000)	0.165 (-0.005)	0.625 (±0.003)	0.187	0.2	0.23
#2-56	Blind Thread	Unified	Stainless Steel, (300 Series)	Passivated	0.025	0.166 (+0.003 / -0.000)	0.165 (-0.005)	0.687 (±0.003)	0.187	0.2	0.23
#2-56	Blind Thread	Unified	Stainless Steel, (300 Series)	Passivated	0.025	0.166 (+0.003 / -0.000)	0.165 (-0.005)	0.75 (±0.003)	0.187	0.2	0.23
#4-40	Full Thread	Unified	Stainless Steel, (300 Series)	Passivated	0.025	0.166 (+0.003 / -0.000)	0.165 (-0.005)	0.09 (±0.003)	0.187	0.22	0.23
#4-40	Full Thread	Unified	Stainless Steel, (300 Series)	Passivated	0.025	0.166 (+0.003 / -0.000)	0.165 (-0.005)	0.125 (±0.003)	0.187	0.22	0.23
#4-40	Full Thread	Unified	Stainless Steel, (300 Series)	Passivated	0.025	0.166 (+0.003 / -0.000)	0.165 (-0.005)	0.187 (±0.003)	0.187	0.22	0.23
#4-40	Full Thread	Unified	Stainless Steel, (300 Series)	Passivated	0.025	0.166 (+0.003 / -0.000)	0.165 (-0.005)	0.25 (±0.003)	0.187	0.22	0.23
#4-40	Partial Thread	Unified	Stainless Steel, (300 Series)	Passivated	0.025	0.166 (+0.003 / -0.000)	0.165 (-0.005)	0.312 (±0.003)	0.187	0.22	0.23
#4-40	Partial Thread	Unified	Stainless Steel, (300 Series)	Passivated	0.025	0.166 (+0.003 / -0.000)	0.165 (-0.005)	0.375 (±0.003)	0.187	0.22	0.23
#4-40	Partial Thread	Unified	Stainless Steel, (300 Series)	Passivated	0.025	0.166 (+0.003 / -0.000)	0.165 (-0.005)	0.437 (±0.003)	0.187	0.22	0.23
#4-40	Blind Thread	Unified	Stainless Steel, (300 Series)	Passivated	0.025	0.166 (+0.003 / -0.000)	0.165 (-0.005)	0.5 (±0.003)	0.187	0.22	0.23
#4-40	Blind Thread	Unified	Stainless Steel, (300 Series)	Passivated	0.025	0.166 (+0.003 / -0.000)	0.165 (-0.005)	0.562 (±0.003)	0.187	0.22	0.23
#4-40	Blind Thread	Unified	Stainless Steel, (300 Series)	Passivated	0.025	0.166 (+0.003 / -0.000)	0.165 (-0.005)	0.625 (±0.003)	0.187	0.22	0.23
#4-40	Blind Thread	Unified	Stainless Steel, (300 Series)	Passivated	0.025	0.166 (+0.003 / -0.000)	0.165 (-0.005)	0.687 (±0.003)	0.187	0.22	0.23
#4-40 (Thread ; Size)	Blind Thread	Unified (Type)	Stainless Steel, (300 Series ; Material)	Passivated (Finish)	0.025 (Sheet ; Min.)	0.166 (+0.003 / -0.000 ; Hole ; Diameter)	0.165 (-0.005 ; A)	0.75 (±0.003 ; L)	0.187 (H ; Nom.)	0.22 (T ; Min.)	0.23 (CL to Edge ; Min.)
#2-56	Partial Thread	Unified	Stainless Steel, (300 Series)	Passivated	0.025	0.213 (+0.003 / -0.000)	0.212 (-0.005)	0.09 (±0.003)	0.25	0.2	0.27
#2-56	Full Thread	Unified	Stainless Steel, (300 Series)	Passivated	0.025	0.213 (+0.003 / -0.000)	0.212 (-0.005)	0.125 (±0.003)	0.25	0.2	0.27
#2-56	Full Thread	Unified	Stainless Steel, (300 Series)	Passivated	0.025	0.213 (+0.003 / -0.000)	0.212 (-0.005)	0.187 (±0.003)	0.25	0.2	0.27
#2-56	Full Thread	Unified	Stainless Steel, (300 Series)	Passivated	0.025	0.213 (+0.003 / -0.000)	0.212 (-0.005)	0.25 (±0.003)	0.25	0.2	0.27
#2-56	Partial Thread	Unified	Stainless Steel, (300 Series)	Passivated	0.025	0.213 (+0.003 / -0.000)	0.212 (-0.005)	0.312 (±0.003)	0.25	0.2	0.27
#2-56	Partial Thread	Unified	Stainless Steel, (300 Series)	Passivated	0.025	0.213 (+0.003 / -0.000)	0.212 (-0.005)	0.375 (±0.003)	0.25	0.2	0.27
#2-56	Blind Thread	Unified	Stainless Steel, (300 Series)	Passivated	0.025	0.213 (+0.003 / -0.000)	0.212 (-0.005)	0.437 (±0.003)	0.25	0.2	0.27
#2-56	Blind Thread	Unified	Stainless Steel, (300 Series)	Passivated	0.025	0.213 (+0.003 / -0.000)	0.212 (-0.005)	0.5 (±0.003)	0.25	0.2	0.27
#2-56	Blind Thread	Unified	Stainless Steel, (300 Series)	Passivated	0.025	0.213 (+0.003 / -0.000)	0.212 (-0.005)	0.562 (±0.003)	0.25	0.2	0.27
#2-56	Blind Thread	Unified	Stainless Steel, (300 Series)	Passivated	0.025	0.213 (+0.003 / -0.000)	0.212 (-0.005)	0.625 (±0.003)	0.25	0.2	0.27
#2-56	Blind Thread	Unified	Stainless Steel, (300 Series)	Passivated	0.025	0.213 (+0.003 / -0.000)	0.212 (-0.005)	0.687 (±0.003)	0.25	0.2	0.27
#2-56	Blind Thread	Unified	Stainless Steel, (300 Series)	Passivated	0.025	0.213 (+0.003 / -0.000)	0.212 (-0.005)	0.75 (±0.003)	0.25	0.2	0.27
#6-32	Full Thread	Unified	Stainless Steel, (300 Series)	Passivated	0.025	0.213 (+0.003 / -0.000)	0.212 (-0.005)	0.125 (±0.003)	0.25	0.27	0.27
#6-32	Full Thread	Unified	Stainless Steel, (300 Series)	Passivated	0.025	0.213 (+0.003 / -0.000)	0.212 (-0.005)	0.187 (±0.003)	0.25	0.27	0.27
#6-32	Full Thread	Unified	Stainless Steel, (300 Series)	Passivated	0.025	0.213 (+0.003 / -0.000)	0.212 (-0.005)	0.25 (±0.003)	0.25	0.27	0.27
#6-32	Full Thread	Unified	Stainless Steel, (300 Series)	Passivated	0.025	0.213 (+0.003 / -0.000)	0.212 (-0.005)	0.312 (±0.003)	0.25	0.27	0.27
#6-32	Partial Thread	Unified	Stainless Steel, (300 Series)	Passivated	0.025	0.213 (+0.003 / -0.000)	0.212 (-0.005)	0.375 (±0.003)	0.25	0.27	0.27
#6-32	Partial Thread	Unified	Stainless Steel, (300 Series)	Passivated	0.025	0.213 (+0.003 / -0.000)	0.212 (-0.005)	0.437 (±0.003)	0.25	0.27	0.27
#6-32	Partial Thread	Unified	Stainless Steel, (300 Series)	Passivated	0.025	0.213 (+0.003 / -0.000)	0.212 (-0.005)	0.5 (±0.003)	0.25	0.27	0.27
#6-32	Blind Thread	Unified	Stainless Steel, (300 Series)	Passivated	0.025	0.213 (+0.003 / -0.000)	0.212 (-0.005)	0.562 (±0.003)	0.25	0.27	0.27
#6-32	Blind Thread	Unified	Stainless Steel, (300 Series)	Passivated	0.025	0.213 (+0.003 / -0.000)	0.212 (-0.005)	0.625 (±0.003)	0.25	0.27	0.27
#6-32	Blind Thread	Unified	Stainless Steel, (300 Series)	Passivated	0.025	0.213 (+0.003 / -0.000)	0.212 (-0.005)	0.687 (±0.003)	0.25	0.27	0.27
#6-32	Blind Thread	Unified	Stainless Steel, (300 Series)	Passivated	0.025	0.213 (+0.003 / -0.000)	0.212 (-0.005)	0.75 (±0.003)	0.25	0.27	0.27
#4-40	Full Thread	Unified	Stainless Steel, (300 Series)	Passivated	0.025	0.213 (+0.003)	0.212 (-0.005)	0.09 (±0.003)	0.25	0.22	0.27
#4-40	Full Thread	Unified	Stainless Steel, (300 Series)	Passivated	0.025	0.213 (+0.003 / -0.000)	0.212 (-0.005)	0.125 (±0.003)	0.25	0.22	0.27
#4-40	Full Thread	Unified	Stainless Steel, (300 Series)	Passivated	0.025	0.213 (+0.003 / -0.000)	0.212 (-0.005)	0.187 (±0.003)	0.25	0.22	0.27
#4-40	Full Thread	Unified	Stainless Steel, (300 Series)	Passivated	0.025	0.213 (+0.003 / -0.000)	0.212 (-0.005)	0.25 (±0.003)	0.25	0.22	0.27
#4-40	Partial Thread	Unified	Stainless Steel, (300 Series)	Passivated	0.025	0.213 (+0.003 / -0.000)	0.212 (-0.005)	0.312 (±0.003)	0.25	0.22	0.27
#4-40	Partial Thread	Unified	Stainless Steel, (300 Series)	Passivated	0.025	0.213 (+0.003 / -0.000)	0.212 (-0.005)	0.375 (±0.003)	0.25	0.22	0.27
#4-40	Partial Thread	Unified	Stainless Steel, (300 Series)	Passivated	0.025	0.213 (+0.003 / -0.000)	0.212 (-0.005)	0.437 (±0.003)	0.25	0.22	0.27
#4-40	Blind Thread	Unified	Stainless Steel, (300 Series)	Passivated	0.025	0.213 (+0.003 / -0.000)	0.212 (-0.005)	0.5 (±0.003)	0.25	0.22	0.27
#4-40	Blind Thread	Unified	Stainless Steel, (300 Series)	Passivated	0.025	0.213 (+0.003 / -0.000)	0.212 (-0.005)	0.562 (±0.003)	0.25	0.22	0.27
#4-40	Blind Thread	Unified	Stainless Steel, (300 Series)	Passivated	0.025	0.213 (+0.003 / -0.000)	0.212 (-0.005)	0.625 (±0.003)	0.25	0.22	0.27
#4-40	Blind Thread	Unified	Stainless Steel, (300 Series)	Passivated	0.025	0.213 (+0.003 / -0.000)	0.212 (-0.005)	0.687 (±0.003)	0.25	0.22	0.27
#4-40	Blind Thread	Unified	Stainless Steel, (300 Series)	Passivated	0.025	0.213 (+0.003 / -0.000)	0.212 (-0.005)	0.75 (±0.003)	0.25	0.22	0.27
M2.5 x 0.45	Blind Thread	Metric	Stainless Steel, (300 Series)	Passivated	0.63	5.41 (+0.08 / -0.000)	5.39 (-0.13)	10 (±0.08)	6.4	5.2	7.1
M2.5 x 0.45	Blind Thread	Metric	Stainless Steel, (300 Series)	Passivated	0.63	5.41 (+0.08 / -0.000)	5.39 (-0.13)	12 (±0.08)	6.4	5.2	7.1
M2.5 x 0.45	Blind Thread	Metric	Stainless Steel, (300 Series)	Passivated	0.63	5.41 (+0.08 / -0.000)	5.39 (-0.13)	14 (±0.08)	6.4	5.2	7.1
M2.5 x 0.45	Blind Thread	Metric	Stainless Steel, (300 Series)	Passivated	0.63	5.41 (+0.08 / -0.000)	5.39 (-0.13)	16 (±0.08)	6.4	5.2	7.1
M2.5 x 0.45	Blind Thread	Metric	Stainless Steel, (300 Series)	Passivated	0.63	5.41 (+0.08 / -0.000)	5.39 (-0.13)	18 (±0.08)	6.4	5.2	7.1
M2.5 x 0.45	Blind Thread	Metric	Stainless Steel, (300 Series)	Passivated	0.63	5.41 (+0.08 / -0.000)	5.39 (-0.13)	19 (±0.08)	6.4	5.2	7.1
M2.5 x 0.45	Full Thread	Metric	Stainless Steel, (300 Series)	Passivated	0.63	5.41 (+0.08 / -0.000)	5.39 (-0.13)	2 (±0.08)	6.4	5.2	7.1
M2.5 x 0.45	Full Thread	Metric	Stainless Steel, (300 Series)	Passivated	0.63	5.41 (+0.08 / -0.000)	5.39 (-0.13)	3 (±0.08)	6.4	5.2	7.1
M2.5 x 0.45	Full Thread	Metric	Stainless Steel, (300 Series)	Passivated	0.63	5.41 (+0.08 / -0.000)	5.39 (-0.13)	4 (±0.08)	6.4	5.2	7.1
M2.5 x 0.45	Full Thread	Metric	Stainless Steel, (300 Series)	Passivated	0.63	5.41 (+0.08 / -0.000)	5.39 (-0.13)	6 (±0.08)	6.4	5.2	7.1
M2.5 x 0.45	Partial Thread	Metric	Stainless Steel, (300 Series)	Passivated	0.63	5.41 (+0.08 / -0.000)	5.39 (-0.13)	8 (±0.08)	6.4	5.2	7.1
M3 x 0.5	Partial Thread	Metric	Stainless Steel, (300 Series)	Passivated	0.63	5.41 (+0.08 / -0.000)	5.39 (-0.13)	10 (±0.08)	6.4	6.2	7.1
M3 x 0.5	Blind Thread	Metric	Stainless Steel, (300 Series)	Passivated	0.63	5.41 (+0.08 / -0.000)	5.39 (-0.13)	12 (±0.08)	6.4	6.2	7.1
M3 x 0.5	Blind Thread	Metric	Stainless Steel, (300 Series)	Passivated	0.63	5.41 (+0.08 / -0.000)	5.39 (-0.13)	14 (±0.08)	6.4	6.2	7.1
M3 x 0.5 (Thread ; Size)	Blind Thread	Metric (Type)	Stainless Steel, (300 Series ; Material)	Passivated (Finish)	0.63 (Sheet ; Min.)	5.41 (+0.08 / -0.000 ; Hole ; Diameter)	5.39 (-0.13 ; A)	16 (±0.08 ; L)	6.4 (H ; Nom.)	6.2 (T ; Min.)	7.1 (CL to Edge ; Min.)
M3 x 0.5	Blind Thread	Metric	Stainless Steel, (300 Series)	Passivated	0.63	5.41 (+0.08 / -0.000)	5.39 (-0.13)	18 (±0.08)	6.4	6.2	7.1
M3 x 0.5	Blind Thread	Metric	Stainless Steel, (300 Series)	Passivated	0.63	5.41 (+0.08 / -0.000)	5.39 (-0.13)	19 (±0.08)	6.4	6.2	7.1
M3 x 0.5	Full Thread	Metric	Stainless Steel, (300 Series)	Passivated	0.63	5.41 (+0.08 / -0.000)	5.39 (-0.13)	2 (±0.08)	6.4	6.2	7.1
M3 x 0.5	Full Thread	Metric	Stainless Steel, (300 Series)	Passivated	0.63	5.41 (+0.08 / -0.000)	5.39 (-0.13)	3 (±0.08)	6.4	6.2	7.1
M3 x 0.5	Full Thread	Metric	Stainless Steel, (300 Series)	Passivated	0.63	5.41 (+0.08 / -0.000)	5.39 (-0.13)	4 (±0.08)	6.4	6.2	7.1
M3 x 0.5	Full Thread	Metric	Stainless Steel, (300 Series)	Passivated	0.63	5.41 (+0.08 / -0.000)	5.39 (-0.13)	6 (±0.08)	6.4	6.2	7.1
M3 x 0.5	Partial Thread	Metric	Stainless Steel, (300 Series)	Passivated	0.63	5.41 (+0.08 / -0.000)	5.39 (-0.13)	8 (±0.08)	6.4	6.2	7.1
M2.5 x 0.45	Blind Thread	Metric	Stainless Steel, (300 Series)	Passivated	0.63	4.22 (+0.08 / -0.000)	4.2 (-0.13)	10 (±0.08)	4.8	5.2	5.8
M2.5 x 0.45	Blind Thread	Metric	Stainless Steel, (300 Series)	Passivated	0.63	4.22 (+0.08 / -0.000)	4.2 (-0.13)	12 (±0.08)	4.8	5.2	5.8
M2.5 x 0.45	Blind Thread	Metric	Stainless Steel, (300 Series)	Passivated	0.63	4.22 (+0.08 / -0.000)	4.2 (-0.13)	14 (±0.08)	4.8	5.2	5.8
M2.5 x 0.45	Blind Thread	Metric	Stainless Steel, (300 Series)	Passivated	0.63	4.22 (+0.08 / -0.000)	4.2 (-0.13)	16 (±0.08)	4.8	5.2	5.8
M2.5 x 0.45	Blind Thread	Metric	Stainless Steel, (300 Series)	Passivated	0.63	4.22 (+0.08 / -0.000)	4.2 (-0.13)	18 (±0.08)	4.8	5.2	5.8
M2.5 x 0.45	Blind Thread	Metric	Stainless Steel, (300 Series)	Passivated	0.63	4.22 (+0.08 / -0.000)	4.2 (-0.13)	19 (±0.08)	4.8	5.2	5.8
M2.5 x 0.45	Full Thread	Metric	Stainless Steel, (300 Series)	Passivated	0.63	4.22 (+0.08 / -0.000)	4.2 (-0.13)	2 (±0.08)	4.8	5.2	5.8
M2.5 x 0.45	Full Thread	Metric	Stainless Steel, (300 Series)	Passivated	0.63	4.22 (+0.08 / -0.000)	4.2 (-0.13)	3 (±0.08)	4.8	5.2	5.8
M2.5 x 0.45	Full Thread	Metric	Stainless Steel, (300 Series)	Passivated	0.63	4.22 (+0.08 / -0.000)	4.2 (-0.13)	4 (±0.08)	4.8	5.2	5.8
M2.5 x 0.45	Full Thread	Metric	Stainless Steel, (300 Series)	Passivated	0.63	4.22 (+0.08 / -0.000)	4.2 (-0.13)	6 (±0.08)	4.8	5.2	5.8
M2.5 x 0.45	Partial Thread	Metric	Stainless Steel, (300 Series)	Passivated	0.63	4.22 (+0.08 / -0.000)	4.2 (-0.13)	8 (±0.08)	4.8	5.2	5.8
M3 x 0.5	Partial Thread	Metric	Stainless Steel, (300 Series)	Passivated	0.63	4.22 (+0.08 / -0.000)	4.2 (-0.13)	10 (±0.08)	4.8	6.2	5.8
M3 x 0.5	Blind Thread	Metric	Stainless Steel, (300 Series)	Passivated	0.63	4.22 (+0.08 / -0.000)	4.2 (-0.13)	12 (±0.08)	4.8	6.2	5.8
M3 x 0.5	Blind Thread	Metric	Stainless Steel, (300 Series)	Passivated	0.63	4.22 (+0.08 / -0.000)	4.2 (-0.13)	14 (±0.08)	4.8	6.2	5.8
M3 x 0.5	Blind Thread	Metric	Stainless Steel, (300 Series)	Passivated	0.63	4.22 (+0.08 / -0.000)	4.2 (-0.13)	16 (±0.08)	4.8	6.2	5.8
M3 x 0.5	Blind Thread	Metric	Stainless Steel, (300 Series)	Passivated	0.63	4.22 (+0.08 / -0.000)	4.2 (-0.13)	18 (±0.08)	4.8	6.2	5.8
M3 x 0.5	Blind Thread	Metric	Stainless Steel, (300 Series)	Passivated	0.63	4.22 (+0.08 / -0.000)	4.2 (-0.13)	19 (±0.08)	4.8	6.2	5.8
M3 x 0.5	Full Thread	Metric	Stainless Steel, (300 Series)	Passivated	0.63	4.22 (+0.08 / -0.000)	4.2 (-0.13)	2 (±0.08)	4.8	6.2	5.8
M3 x 0.5	Full Thread	Metric	Stainless Steel, (300 Series)	Passivated	0.63	4.22 (+0.08 / -0.000)	4.2 (-0.13)	3 (±0.08)	4.8	6.2	5.8
M3 x 0.5	Full Thread	Metric	Stainless Steel, (300 Series)	Passivated	0.63	4.22 (+0.08 / -0.000)	4.2 (-0.13)	4 (±0.08)	4.8	6.2	5.8
M3 x 0.5	Full Thread	Metric	Stainless Steel, (300 Series)	Passivated	0.63	4.22 (+0.08 / -0.000)	4.2 (-0.13)	6 (±0.08)	4.8	6.2	5.8
M3 x 0.5 (M3.5 x 0.5)	Partial Thread	Metric (Metric)	Stainless Steel, (300 Series ; Stainless Steel, ; 300 Series)	Passivated (Passivated)	0.63 (+0.63)	4.22 (+0.08 / +5.41 / +0.08 / -0.000 / -0.000)	4.2 (+5.39 / -0.13 / -0.13)	8 (+10 ; ±0.08 ; ±0.08)	4.8 (+6.4)	6.2 (+7)	5.8 (+7.1)
M3.5 x 0.5	Partial Thread	Metric	Stainless Steel, (300 Series)	Passivated	0.63	5.41 (+0.08 / -0.000)	5.39 (-0.13)	12 (±0.08)	6.4	7	7.1
M3.5 x 0.5	Blind Thread	Metric	Stainless Steel, (300 Series)	Passivated	0.63	5.41 (+0.08 / -0.000)	5.39 (-0.13)	14 (±0.08)	6.4	7	7.1
M3.5 x 0.5	Blind Thread	Metric	Stainless Steel, (300 Series)	Passivated	0.63	5.41 (+0.08 / -0.000)	5.39 (-0.13)	16 (±0.08)	6.4	7	7.1
M3.5 x 0.5	Blind Thread	Metric	Stainless Steel, (300 Series)	Passivated	0.63	5.41 (+0.08 / -0.000)	5.39 (-0.13)	18 (±0.08)	6.4	7	7.1
M3.5 x 0.5	Blind Thread	Metric	Stainless Steel, (300 Series)	Passivated	0.63	5.41 (+0.08 / -0.000)	5.39 (-0.13)	19 (±0.08)	6.4	7	7.1
M3.5 x 0.5	Full Thread	Metric	Stainless Steel, (300 Series)	Passivated	0.63	5.41 (+0.08 / -0.000)	5.39 (-0.13)	3 (±0.08)	6.4	7	7.1
M3.5 x 0.5	Full Thread	Metric	Stainless Steel, (300 Series)	Passivated	0.63	5.41 (+0.08 / -0.000)	5.39 (-0.13)	4 (±0.08)	6.4	7	7.1
M3.5 x 0.5	Full Thread	Metric	Stainless Steel, (300 Series)	Passivated	0.63	5.41 (+0.08 / -0.000)	5.39 (-0.13)	6 (±0.08)	6.4	7	7.1
M3.5 x 0.5	Full Thread	Metric	Stainless Steel, (300 Series)	Passivated	0.63	5.41 (+0.08 / -0.000)	5.39 (-0.13)	8 (±0.08)	6.4	7	7.1

Disposal

Dispose as scrap metal in accordance with local regulations.

GET IN TOUCH
