MSDS – ESD Kapton (Polyimide) Tape
Description
ESD-safe Kapton polyimide backing with silicone adhesive, offering excellent electrical insulation and outstanding thermal resistance for demanding production environments. Common uses include protecting PCB gold fingers during wave soldering, serving as a ground barrier and phase insulation in high-performance toroidal coils, and acting as an outer wrap on small bobbin-wound coils and on form-wound coils for traction motors.
Key Features
- Polyimide (Kapton) film with silicone adhesive
- High-temperature masking and insulation in electronics assembly
- Good toughness and puncture resistance
- Flame-retardant construction
- Electrostatic discharge (ESD) safe
Technical Data
| Property | Value | Test Method / Notes |
|---|---|---|
| Backing | Polyimide (Kapton) | — |
| Adhesive | Silicone | — |
| Colour | Amber (typical) | — |
| Thermal Resistance | High-temperature applications | See product specification |
| Electrical Insulation | Excellent | See product specification |
| Flame Retardance | Yes | See product specification |
| Tape Length | 33 m (all widths) | Standard roll length |
| Shelf Life | 12 months | Store boxed, dry, out of direct sunlight |
Applications
- Masking and protection of PCB gold fingers during wave soldering
- Ground barrier and phase insulation in toroidal coils
- Outer wrap on small bobbin-wound coils
- Insulation on form-wound coils for traction motors
Available Sizes / Part Numbers
All tapes are supplied in standard 33 m roll length.
| Part Number (P/N) | Width | Core |
|---|---|---|
| 1306-10101 | 2 mm | Plastic |
| 1306-10102 | 4 mm | Plastic |
| 1306-10102 | 6 mm | Plastic |
| 1306-10103 | 8 mm | Plastic |
| 1306-10106 | 10 mm | Plastic |
| 1306-10107 | 12 mm | Plastic |
| 1306-10108 | 16 mm | Plastic |
| 1306-10109 | 18 mm | Plastic |
| 1306-10110 | 19 mm | Plastic |
| 1306-10111 | 20 mm | Plastic |
| 1306-10112 | 22 mm | Plastic |
| 1306-10113 | 24 mm | Plastic |
| 1306-10114 | 25 mm | Plastic |
| 1306-10116 | 15 mm | Plastic |
| 1306-10117 | 35 mm | Plastic |
| 1306-10115 | 40 mm | Plastic |
| 1306-10118 | 3 mm | Plastic |
Handling & Storage
- Store in a cool, dry environment away from direct sunlight.
- Keep product boxed until use to prevent contamination.
- Use with clean gloves in ESD-controlled areas where applicable.
| Document No.: MSDS-1306-KPT-ESD | Revision: 01 | Date of Issue: 26 Oct 2025 |
This is a controlled document. Uncontrolled if printed or stored outside of the official Sucatec document system.
